WAGONR S-CNG
Maruti Suzuki, in its endeavour to push forward the cause of green mobility, has launched the Maruti Suzuki Wagon R CNG. The new Wagon R CNG comes with a new body and design that still remains true to its original “tall-boy” stance. At its heart, the Maruti Suzuki Wagon R CNG employs the S-CNG technology that provides a perfect balance of drivability and high fuel efficiency.
S-CNG technology is available in Wagon R LXI and LXI (O) CNG variants. The factory fitted CNG kit in Maruti Suzuki Wagon R CNG has a leak proof design thanks to the advanced components used, and contributes to a higher engine lifespan. Equipped with dual interdependent ECUs with Intelligent Injection System, Wagon R CNG delivers superior performance that is characterized by smooth pickup and great drivability. The total CNG tank capacity in Wagon R S-CNG stands at 60L (water equivalent).
WagonR S-CNG Features
| SPECIFICATIONS |
LXI CNG 1.0L |
LXI (O) CNG 1.0L |
Dimensions
| Length |
3655 mm |
3655 mm |
| Width |
1620 mm |
1620 mm |
| Height |
1675 mm |
1675 mm |
| Wheelbase |
2435 mm |
2435 mm |
| Turning Radius |
4.7 m |
4.7 m |
Engine
| Engine Type |
K10B |
K10B |
| Capacity |
998 cc |
998 cc |
| Number of Cylinders |
3 |
3 |
| Maximum Engine Output (CNG) |
43.5 kW @ 5500 rpm |
43.5 kW @ 5500 rpm |
| Maximum Torque (CNG) |
78 Nm @ 3500 rpm |
78 Nm @ 3500 rpm |
| Emission Type |
BS6 + OBD-I |
BS6 + OBD-I |
| Maximum Engine Output (Petrol) |
50 kW @ 5500 rpm |
50 kW @ 5500 rpm |
| Maximum Torque (Petrol) |
90 Nm @ 3500 rpm |
90 Nm @ 3500 rpm |
SUSPENSION
| Front |
MacPherson Strut with Coil Spring |
MacPherson Strut with Coil Spring |
| Rear |
Torsion Beam with Coil Spring |
Torsion Beam with Coil Spring |
Capacity
| Seating Capacity |
5 |
5 |
| Fuel Tank Capacity (CNG) |
60 L |
60 L |
| Fuel Tank Capacity (Petrol) |
32 L |
32 L |
Tyres
| Size |
155/80R13 |
155/80R13 |
| Type |
Radial & Tubeless |
Radial & Tubeless |
Brakes
| Front |
Disc |
Disc |
| Rear |
Drum |
Drum |
Weight
| Kerb Weight |
905 kg |
905 kg |
| Gross Vehical Weight |
1340 kg |
1340 kg |
Transmission
| MT |
 |
|
*Black glass on the vehicles is due to lighting effect
**Car models and accessories shown may vary from actual product. Images are used for illustration purpose only
* Test results are of Rule115 of CMVR,1989.
* Prices shown above are ex showroom Delhi.
WagonR S-CNG FAQs
01. General
What are the different modes for driving the new Wagon R S-CNG?
- Basically, there are three modes for driving the Wagon R S-CNG, namely: -
• Petrol mode – the car starts and drives entirely on petrol
• Auto mode – this is a company recommended mode wherein the car starts on petrol but then automatically switches over to CNG once on the move.
• Forced CNG mode – here, you can start the car on CNG. However, this mode is advisable only when there is no petrol in the car.
The CNG malfunctioning light in my Wagon R S-CNG keeps glowing when I drive. What should I do?
- Since there can be many different reasons behind this, it is recommended that you take the car to the nearest Maruti Suzuki service centre.
Is it okay to get Wagon R S-CNG tuned from outside?
- Getting the CNG kit tuned from outside is not recommended. The Wagon R S-CNG comes with a company fitted CNG kit and the exact tuning of these kits will only be available at an authorised Maruti Suzuki service centre.
How frequently should I get the S-CNG kit checked?
- It is recommended to get the kit checked at least once in three years for better service. This includes the CNG pipeline setup, electrical harness, and the CNG tank itself which has a tank capacity of 60L (water equivalent). You can visit the nearest service centre for the same.
